Battery Powered BlueTooth Speaker Kit with Voltmeter. Detailed. The Blue Tooth Ammo Can Kit was designed to be a rugged and dependable stereo speaker for enthusiasts who appreciate superior design, quality construction and dependable components with a rugged Americana aesthetic. In order to complete the kit you will need to cut speaker and mounting holes in a 50. The Blue Tooth Ammo Can Kit was designed to be a rugged and dependable stereo speaker for enthusiasts who appreciate superior design, quality construction and dependable components with a rugged Americana aesthetic. In order to complete the kit you will need to cut speaker and mounting holes in a 50 cal or larger ammo can. There is metalworking fabrication required for the kit to be installed. All of the electronics are pre-assembled and wired for easy connection. Holes sizes and locations for the fabrication will be provided via full size paper templates. You will need to supply the 50 cal ammo can and metalworking. If you would like to buy a pre-assembled BT AmmoCan or you would like to buy a 50 cal can already machined to spec both of these other items are available in this store. 。This Bluetooth speaker kit is the culmination of dozens of BT AmmoCan builds and this kit includes the most popular features requested in the past year of production. I believe this unit has the best selection of off the shelf components with custom manufactured bracket assemblies coupled with superb attention to detail.。All purchased components have been thoroughly vetted and chosen to have a long operational life. Fabricated components were designed and made to ensure solid performance for years of use. This kit contains all the components along with the instructions and templates on how to fabricate your own AmmoCan speaker. You need to supply the 50 cal ammo can and do the work to create your own custom BlueTooth speaker. Look to the other listing in STEMandStuff for fully machined 50 caliber box to use with this kit.。Major Components of the Blue Tooth Ammo Can Speaker Kit:。BLUETOOTH MODULE: Mounted onto a custom designed thermoplastic port is a Bluetooth 4.0 Audio Receiver Amplifier Board with a range up to 33 ft. Internal fasteners are 4-40 stainless steel socket head cap screws (SHCS) fastened into brass thermal set threaded inserts.。SPEAKERS: Unit comes with Kicker 2-Way Co-axial 4" polypropylene woofer with ribbed polyester foam surround and 1/2" PEI domed tweeter rated at 120 watts peak power each. Speakers are secured with alloy black oxide 8-32 button head cap screws (BHCS), plated nuts and stainless steel nyloc nuts to remain tight over years of extended use.。REFLEX PORT: Tuned reflex port allows increased low frequency response and provides a secure mounting source for the Blue Tooth Module. The vented port allows for optimum bass response and is mounted onto the side of the ammo speaker box. The port assembly was designed specifically for this enclosure. The port is assembled with alloy black oxide 8-32 button head cap screws (BHCS) and are secured with fully captured stainless steel nyloc nuts.。BATTERY: Sealed lead acid 12V 5Ah battery is cradled in a custom designed battery support tray with stout nylon tie strap retention. Battery is rated for 60W and will provide over 30 hours of blue tooth radio use at moderate volume. Powering USB devices through the USB port will reduce play time. Battery tray and battery top strap is secured to the enclosure with alloy black oxide 8-32 button head cap screws (BHCS) on the underside of the box in the handle recess. An 18” heavy duty zip tie is provided to attach the battery and top strap to the mounted bracket.。The Gel Cell 12V lead acid battery should be charged with a trickle charger with a float option. Over discharging the battery (below 11.2V will cause damage to the battery). When in doubt a trickle charge will extend battery performance and extend battery life.。ON/OFF SWITCH: Power switch is mounted onto the front of the ammo speaker box and controls all power coming from the battery (USB port will not function with switch off). Battery can still be charged through the connector when the main power switch is off. The unit can function both as a speaker and as a USB supply while plugged into charger and switched to the on position. Switch is held into position with a custom designed reinforcement PET-G molded brace with uses SS 4-40 SHCS locking screw.。FUSE: The unit is shipped with the fuse disconnected. Fuse is a 5x20mm AGC fuse (miniature inline) rated at 3A fuse. Reconnect the fuse prior to initial use.。VOLTMETER: Know the state of charge of your batter with a quick glance. This low power consuming voltmeter provides an accurate measurement of the battery level. (Alternate: The wiring harness and hole cutout can mount another 12V accessory that you could supply using spade terminals)。BATTERY CHARGER PLUG: The battery may be charged through the battery connector cable. The battery charging plug is a 5.5mm x 2.1mm female plug that uses a custom molded support brace. The brace is internally threaded to match the M11X1.0 threads of the plug and uses a SS 4-40 SHCS locking screw. A trickle charger with float is required to charge the battery using the switch. Fabrication notes for the de power plug are available upon request.。WIRING HARNESS: A dedicated wiring harness assembly has been provided for easy connection between all the components. The harness includes a euro style isolation strip, color coded and fused primary power leads, charging power lead, switch leads and the main multi harness. All harness connections are complete and the unit will be shipped fully wired (power disconnected from battery for safety during shipping).。FASTENERS: All threaded connections bolt securely into either steel nuts or into thermally fused brass inserts. All fasteners are either 4-40 or 8-32 threads with button head cap screws. Never worry about threads stripping out in plastic!。All non soldered electrical connections utilize crimped wire ferrules and are connected with an industry standard nylon insulated terminal strip. Crimped ferrules mechanically reinforce the stranded wire at the terminal strip. The use of wire ferrules and a dedicated terminal strip provides a strong mounting location for all electrical connections. Electrical components will come assembled and the Bluetooth stereo system can be used in any equivalently sized container. Previous customers have mounted this system in old tool boxes and in old luggage.。INSTRUCTIONS: A detailed instruction manual is provided with the kit includes fabrication notes, recommended assembly order along with technical illustrations to assist identification of major components. The instructions are specifically geared towards installation into a 50 caliber ammo can but are also applicable if mounting the kit into another enclosure.。TEMPLATES: Four full size (B-sized 11" x 17") heavy weight paper are supplied. One for the Front, Port Side, Back and Latch Side. Templates can be affixed using tape or spray adhesive. All holes can be marked directly from the templates or utilizing mounted components such as a guide (battery mount holes on the bottom of the box).。RECOMMENDED TOOLS:。3/32” Hex Wrench (for #4 SHCS and #8 BHCS)。11/32” box wrench or socket。14mm box wrench or socket。3 ¾” (or 3 5/8") Hole Saw (Metal Cutting) [4" speaker]。2 1/8” (or 2") Hole Saw (Metal Cutting) [Reflex Port]。1/8” drill bit。3/16" or 13/64” drill bit (clearance hole for #8 machine screw)。Step Bit up to 1 1/8” diameter [USB charger, rocker switch and Voltmeter ]。Half Round File or rotary tool (for deburring) (or 1 1/8" Hole Saw)。Center Punch。A completed blue system provided mounted into a 50 cal Ammo Can will weigh 11.5lbs.。TO OPERATE:。When On/Off switch is set to On (1) the Bluetooth module will query local bluetooth devices and attempt to connect to a controlling device (cell phone, computer etc). This may take several seconds and will make a series of tones to indicate that the bluetooth module is operational. Your bluetooth device can then link to the BT AmmoCan speaker box. All aspects of the speaker box such as volume, mute, song skip etc will be driven by the linked bluetooth device.。To turn off the BT AmmoCan turn the On/Off rocker switch to 0.。THANKS FOR YOUR INTEREST!。I have tried to build the best quality BT speaker lit with the best components available and I am always trying to improve the design and add features. If you have any comments I would love to hear them. If you have any questions during your build I have provided contact information for technical support.。Thank you looking!。
